Geometry-consistent statistical workflows
Source:vignettes/geometry-workflows.Rmd
geometry-workflows.RmdA geometry specifies the distances and operations used by an analysis. Select it before fitting, inspect the numerical result, and reuse the fitted object for new observations. The examples below use small synthetic observations. They illustrate software behavior, without making scientific claims about an application dataset.
Validate observations and select a geometry
Construct positive-definite matrices by exponentiating real symmetric matrices. The off-diagonal chart entries give noncommuting observations.
matrix_exp <- function(a) {
e <- eigen(a, symmetric = TRUE)
e$vectors %*% diag(exp(e$values)) %*% t(e$vectors)
}
t <- seq(-0.6, 0.6, length.out = 12)
matrices <- lapply(t, function(a) {
matrix_exp(matrix(c(a, 0.2 * sin(3 * a), 0.2 * sin(3 * a), -0.5 * a), 2))
})
x <- wrap.spd(matrices)
airm <- riem.geometry(x, "affine_invariant")
log_euclidean <- riem.geometry(x, "log_euclidean")
airm
#> Geometry: affine_invariant on spd
#> Representation: 2 x 2 ; intrinsic dimension: 3
#> Validation: core_contract
log_euclidean
#> Geometry: log_euclidean on spd
#> Representation: 2 x 2 ; intrinsic dimension: 3
#> Validation: core_contractAffine-invariant and log-Euclidean distances describe different
problems. The legacy SPD names "intrinsic" and
"extrinsic" resolve to these two choices, respectively. The
capability table records which operation routes are available; its
validation status also identifies families still awaiting a broader
audit.
capability <- riem.capabilities()
capability[capability$manifold_id %in% c("spd", "sphere", "landmark"), ]
#> manifold_id backend geometry_id distance mean median tangent
#> 1 spd intrinsic affine_invariant TRUE TRUE TRUE TRUE
#> 2 sphere intrinsic round TRUE TRUE TRUE TRUE
#> 4 landmark intrinsic shape_orthogonal TRUE TRUE TRUE TRUE
#> 11 spd extrinsic log_euclidean TRUE TRUE TRUE TRUE
#> 12 sphere extrinsic chordal TRUE TRUE TRUE FALSE
#> 14 landmark extrinsic procrustes_chordal TRUE FALSE FALSE FALSE
#> validation_status median_estimand
#> 1 core_contract frechet_median
#> 2 core_contract frechet_median
#> 4 audit_pending frechet_median
#> 11 core_contract frechet_median
#> 12 core_contract projected_ambient_median
#> 14 audit_pending projected_ambient_medianPositive definiteness is checked independently of full rank. This deliberately invalid example must produce an error; the vignette verifies that the error occurs.
Inspect a numerical summary
The shared solver records its objective and termination state. A finite matrix by itself is not a convergence certificate.
m <- riem.mean(x, geometry = airm, maxiter = 200, eps = 1e-8, trace = TRUE)
m
#> Geometric mean under affine_invariant on spd
#> Termination: stationary ; converged: TRUE ; iterations: 4
#> Objective: 0.224607
#> Estimand: intrinsic_frechet_mean
#> [,1] [,2]
#> [1,] 1.000000e+00 -1.663168e-10
#> [2,] -1.663168e-10 1.000000e+00
stopifnot(m$converged)
c(objective = m$objective, iterations = m$iterations)
#> objective iterations
#> 0.224607 4.000000
mlog <- riem.mean(x, geometry = log_euclidean)
stopifnot(mlog$converged)
riem.median(x, geometry = log_euclidean, maxiter = 200)
#> Geometric median under log_euclidean on spd
#> Termination: stationary ; converged: TRUE ; iterations: 0
#> Objective: 0.41860924
#> Estimand: extrinsic_frechet_median
#> [,1] [,2]
#> [1,] 1.000000e+00 -2.489623e-18
#> [2,] -2.489623e-18 1.000000e+00Fit, predict, and reconstruct tangent components
Tangent PCA approximates variation near a trained reference. It retains a metric-preserving coordinate convention and any coordinate offset. Its explained variance is a property of this tangent representation, rather than exact global variance on the manifold.
pca <- riem.pga(x, ndim = 2, geometry = log_euclidean)
pca
#> Tangent PCA on spd ( log_euclidean )
#> 12 observations; 2 components retained; numerical rank 2
summary(pca)
#> Variance explained in the fitted tangent representation
#> PC1 PC2
#> variance 0.2435162 0.001509638
#> proportion 0.9938389 0.006161138
#> cumulative 0.9938389 1.000000000
stopifnot(isTRUE(all.equal(unname(predict(pca, x)), unname(pca$embed))))
new_x <- wrap.spd(list(matrix_exp(matrix(c(0.15, 0.08, 0.08, -0.1), 2))))
new_scores <- predict(pca, new_x)
new_scores
#> PC1 PC2
#> [1,] 0.2107759 0.01932642
approximation <- riem.reconstruct(pca, new_scores)
approximation$data[[1]]
#> [,1] [,2]
#> [1,] 1.17698470 0.08355381
#> [2,] 0.08355381 0.92632326
stopifnot(min(eigen(approximation$data[[1]], symmetric = TRUE)$values) > 0)Prediction and reconstruction use the saved reference. With fewer components than the data’s rank, reconstruction is an approximation. Requests above numerical rank are truncated with a warning and the effective dimension is recorded.
The sphere uses an orthonormal tangent basis. The following observations lie in a small neighborhood where the reference and logarithms are well defined.
sphere <- wrap.sphere(cbind(rep(1, 10), matrix(rnorm(20, sd = 0.08), 10, 2)))
sphere_pca <- riem.pga(sphere, ndim = 2, geometry = "round")
reconstructed <- riem.reconstruct(sphere_pca)
stopifnot(all(vapply(reconstructed$data, function(a) abs(sum(a^2) - 1) < 1e-10,
logical(1))))
plot(sphere_pca)
Antipodal logarithms are nonunique. Unsupported geometry-operation combinations also produce explicit errors rather than silently switching metrics.
unsupported <- tryCatch(riem.pga(sphere, geometry = "chordal"), error = identity)
stopifnot(inherits(unsupported, "error"))
conditionMessage(unsupported)
#> [1] "Geometry 'chordal' does not support tangent with a compatible implementation."Reuse a clustering model
The default Lloyd driver uses the shared mean solver and records each start. Labels returned by prediction refer to the final trained centers.
set.seed(1702)
clusters <- riem.kmeans(x, k = 2, geometry = log_euclidean, nstart = 2)
clusters
#> Manifold k-means: 2 clusters on log_euclidean
#> Within-cluster sum of squares: 0.6083241 ; termination: stable_assignment
clusters$starts
#> start valid converged termination objective iterations empty_clusters
#> 1 1 TRUE TRUE stable_assignment 0.6083241 3 0
#> 2 2 TRUE TRUE stable_assignment 0.6083241 1 0
#> error
#> 1
#> 2
stopifnot(identical(predict(clusters, x), clusters$cluster))
predict(clusters, new_x)
#> [1] 1Tune scalar-response regression using every held-out fold
Here the predictor is a matrix and the response is numeric. Geometry is fixed before tuning. The fold assignments are stored and every observation contributes once to the held-out sum of squared errors. For grouped or temporal data, supply splits appropriate to the sampling design. If preprocessing is learned from data, it must be repeated within the corresponding training folds.
y <- sin(2 * t) + rnorm(length(t), sd = 0.03)
regression <- riem.m2skregCV(
x, y, geometry = log_euclidean, bandwidths = c(0.1, 0.25, 0.5),
foldid = rep(1:3, length.out = length(t))
)
regression$errors
#> bandwidth SSE
#> [1,] 0.10 0.05392788
#> [2,] 0.25 0.14691578
#> [3,] 0.50 0.99031984
regression$fold_errors
#> 1 2 3
#> [1,] 0.01809862 0.007890027 0.02793924
#> [2,] 0.03641123 0.029304317 0.08120023
#> [3,] 0.29816855 0.264589651 0.42756163
prediction <- predict(regression, new_x, diagnostics = TRUE)
prediction
#> $prediction
#> [1] 0.2900565
#>
#> $diagnostics
#> effective_n nearest_distance nearest_over_bandwidth
#> 1 2.408551 0.03040861 0.3040861
stopifnot(identical(regression$geometry$geometry_id, "log_euclidean"))A finite prediction can still have weak local support. Effective neighborhood size and distance relative to bandwidth help assess that limitation; numerical stability does not establish statistical support.
Preserve the fitted state
path <- tempfile(fileext = ".rds")
saveRDS(pca, path)
restored <- readRDS(path)
unlink(path)
stopifnot(isTRUE(all.equal(predict(restored, new_x), new_scores)))
sessionInfo()
#> R version 4.5.2 (2025-10-31)
#> Platform: aarch64-apple-darwin20
#> Running under: macOS Tahoe 26.6.2
#>
#> Matrix products: default
#> BLAS: /System/Library/Frameworks/Accelerate.framework/Versions/A/Frameworks/vecLib.framework/Versions/A/libBLAS.dylib
#> LAPACK: /Library/Frameworks/R.framework/Versions/4.5-arm64/Resources/lib/libRlapack.dylib; LAPACK version 3.12.1
#>
#> locale:
#> [1] C.UTF-8/C.UTF-8/C.UTF-8/C/C.UTF-8/C.UTF-8
#>
#> time zone: America/New_York
#> tzcode source: internal
#>
#> attached base packages:
#> [1] stats graphics grDevices utils datasets methods base
#>
#> other attached packages:
#> [1] Riemann_0.2.0
#>
#> loaded via a namespace (and not attached):
#> [1] tidyselect_1.2.1 hdrcde_3.5.0 dplyr_1.2.1
#> [4] farver_2.1.2 bitops_1.1-0 S7_0.2.2
#> [7] RCurl_1.98-1.20 fastmap_1.2.0 pracma_2.4.6
#> [10] maotai_0.3.0 RANN_2.6.3 digest_0.6.39
#> [13] lifecycle_1.0.5 cluster_2.1.8.3 rstiefel_1.0.1
#> [16] magrittr_2.0.5 dbscan_1.2.6 compiler_4.5.2
#> [19] rlang_1.3.0 sass_0.4.10 tools_4.5.2
#> [22] mclustcomp_0.3.5 yaml_2.3.12 knitr_1.51
#> [25] htmlwidgets_1.6.4 scatterplot3d_0.3-45 mclust_6.1.3
#> [28] RColorBrewer_1.1-3 rainbow_3.8 KernSmooth_2.23-27
#> [31] fda_6.3.0 Rtsne_0.17 desc_1.4.3
#> [34] pcaPP_2.0-5 grid_4.5.2 clarabel_0.11.3
#> [37] colorspace_2.1-3 ADMM_0.3.4 T4cluster_0.1.4
#> [40] fastcluster_1.3.0 ggplot2_4.0.3 scales_1.4.0
#> [43] iterators_1.0.14 MASS_7.3-66 mvtnorm_1.4-2
#> [46] cli_3.6.6 rmarkdown_2.31 ragg_1.5.2
#> [49] generics_0.1.4 otel_0.2.0 RSpectra_0.16-2
#> [52] RcppDE_0.1.9 CVXR_1.9.2 scs_3.2.7
#> [55] fds_1.9 cachem_1.1.0 splines_4.5.2
#> [58] parallel_4.5.2 vctrs_0.7.3 T4transport_0.1.9
#> [61] Matrix_1.7-6 jsonlite_2.0.0 systemfonts_1.3.2
#> [64] foreach_1.5.2 gsignal_0.3-7 jquerylib_0.1.4
#> [67] glue_1.8.1 pkgdown_2.2.1 codetools_0.2-20
#> [70] DEoptim_2.2-8 gtable_0.3.6 osqp_1.0.0
#> [73] gmp_0.7-5.1 tibble_3.3.1 pillar_1.11.1
#> [76] htmltools_0.5.9 deSolve_1.42 R6_2.6.1
#> [79] textshaping_1.0.5 Rdpack_2.6.6 ks_1.15.3
#> [82] doParallel_1.0.17 lpSolve_5.6.23 evaluate_1.0.5
#> [85] lattice_0.23-1 rbibutils_2.4.1 backports_1.5.1
#> [88] highs_1.14.0-2 bslib_0.12.0 Rcpp_1.1.2
#> [91] checkmate_2.3.4 xfun_0.60 fs_2.1.0
#> [94] Rdimtools_1.1.5 pkgconfig_2.0.3Regular landmark tangent workflows use equivalence under the full orthogonal group, including reflections, and align new observations to the trained reference. Singular alignments and reconstructions outside the supported local chart are rejected. This convention must agree with the scientific meaning of the landmarks; it is not an orientation-preserving shape convention.
